MPEG-H Audio Brings New Dimensions To Tv Sound
audioXpress|June 2018

Fraunhofer Institute for Integrated Circuits IIS designed a way to significantly improve immersive sound reproduction capabilities on consumer playback devices, based on MPEG-H decoding and rendering and Fraunhofer’s upHear soundbar processing. This article is a technology update on MPEG-H and Fraunhofer upHear implementations, now available for licensing to audio video receiver (AVR) and soundbar manufacturers.

Stefan Meltzer
MPEG-H Audio Brings New Dimensions To Tv Sound

Imagine watching a crime drama on TV. The detective interrogates a suspect as suspense-filled music plays in the background. The back-and-forth dialog, however, is hard to understand because of the music’s volume. A similar dilemma happens while watching a live sports broadcast, where the commentary drowns out the stadium atmosphere. TV stations have to deal with issues like these all the time. They have to find a compromise in the audio mix that suits a diverse audience. What would change the game is enabling viewers to change the audio playback to their own preferences.

The MPEG-H TV Audio System, substantially developed by Fraunhofer IIS, is designed to offer new interactive options for the viewer as well as deliver immersive 3D sound. The format is integrated in the ATSC 3.0 and DVB television standards. It has been on air in South Korea since May 2017 as part of the world’s first regular terrestrial UHDTV service. MPEG-H, however, is not only a new audio codec, but a complete system—from the microphone to the loudspeaker— and opens up new options for creatives as well as new sound dimensions for viewers.

MPEG-H Audio: Creative Freedom Through Channels, Objects, and Ambisonics

MPEG-H offers three dimensions of efficient audio transmission: channels, objects, and ambisonics. Channel-based audio ensures, among other things, that all conventional content can be broadcast using MPEG-H . Additionally, the capabilities of channel-based audio are enhanced by the introduction of height channels, enabling the playback of true 3D immersive sound. For usage in ATSC 3.0 and DVB, the number of available loudspeaker channels in the MPEG-H TV Audio System is limited to 12. That way, common formats such as 5.1+4 and 7.1+4 are possible. For the Japanese market, the MPEG standard allows for a variant that supports the 22.2 system proposed in Japan.
